X-ray television installation (introscope) Astrophysics “XIS 1818 (200)”
X-ray television installation Astrophysics “XIS 1818 (200)”
The XIS-1818 is a high-performance X-ray inspection system with an increased tunnel size of 180.4 cm x 180.4 cm. The XIS-1818 200kV is designed for the inspection of large and palletized cargo at airports and seaports, it is also ideal for any location where large inspection systems are required.
Due to the high strength and rigidity of the structure, the XIS-1818 200kV roller conveyor can withstand loads of up to 3000 kg. XIS-1818 200kV provides high performance while maintaining high throughput.
The combination of the special capabilities of Astrophysics software and advanced technology allows the XIS-1818 200kV to be used to solve a wide range of inspection tasks.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials. A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 1804 x 1804 mm |
| Overall dimensions, no more | 7312 mm x 2897 mm x 2357 mm |
| Packaging dimensions | 1x 3251 mm x 1435 mm x 2540 mm
2x 2311 mm x 1435 mm x 2540 mm 2x 2032 mm x 2235 mm x 813 mm |
| Weight, no more | 4450 kg |
| Package weight | 5700 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 3000 kg |
| Conveyor height | 386 mm |
| Conveyor belt speed | 0.10 m/s |
| X-ray source | |
| Anode voltage | 200 kV |
| Source current | 1.2 mA |
| Radiation direction | horizontally to the side |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.07 mm (40 AWG) – 0.08 mm (38 AWG) |
| Penetration ability on steel | 52 – 50 mm |
| Spatial resolution, line pairs per mm | 1.3 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | Two 24” LCD monitors
1600 x 1200, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
