X-ray television installation (introscope) Astrophysics “XIS 5335S”
X-ray television installation Astrophysics «XIS5335S»
XIS-5335S is a compact X-ray television installation with a tunnel size of 53.3 cm x 35.6 cm. Designed for inspection of small objects: mail, handbags, briefcases, etc.
XIS-5335S are used in post offices, at entrances to government and public buildings, in business centers, entertainment centers, and cultural institutions. Due to its small size, the unit is easy to move.
XIS-5335S allows you to organize an inspection point in a limited area. The installation combines high quality and low price.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 533 x 356 mm |
| Overall dimensions, no more | 1313 x 764 x 1225 mm |
| Packaging dimensions | 1448 x 863 x 1650 mm |
| Weight, no more | 345 kg |
| Package weight | 505 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 165 kg |
| Conveyor height | 729 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 160 kV (operating 150 kV) |
| Source current | 0.7 mA |
| Radiation direction | diagonally up |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.08 mm (40 AWG) – 0.10 mm (38 AWG) |
| Penetration ability on steel | 39 – 37 mm |
| Spatial resolution, line pairs per
mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | LCD monitor 19”
1280 x 1024, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
