X-ray television installation (introscope) Astrophysics “XIS-6040NM”
X-ray television installation Astrophysics “XIS-6040NM”
The XIS-6040NM mobile X-ray inspection unit with a tunnel size of 60 cm x 40 cm is ideal for inspecting hand luggage and postal items. With such a tunnel, the model is quite compact, which allows the device to be moved and placed in the limited area of many checkpoints.
The small-sized introscope “XIS-6040NM” is a universal solution; the device is equally applicable in government and public buildings, hotels, prisons, and various transport hubs.
A powerful 160kV generator along with advanced software allows for clear, high-resolution images.
All systems from Astrophysics are equipped with a system of continuous condition diagnostics. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces operating costs and possible repairs.
Another feature of Astrophysics installations is the formation of images of inspected objects in a six-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 600 x 400 mm |
| Overall dimensions, no more | 1412 x 809 x 1337 mm |
| Packaging dimensions | 1588 x 965 x 1778 mm |
| Weight, no more | 370 kg |
| Package weight | 490 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 165 kg |
| Conveyor height | 800 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 160 kV (operating 150 kV) |
| Source current | 0.7 mA |
| Radiation direction | diagonally up |
| Cooling system | oil bath with air
(convection) cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.08 mm (40 AWG) – 0.10 mm (38 AWG) |
| Penetration ability on steel | 39 – 37 mm |
| Spatial resolution, line pairs per
mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | LCD monitor 19”
1280 x 1024, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
