Arched metal detector BLOKPOST RS-600
The device is used to identify metal objects that may be in personal belongings, clothing, luggage, hand luggage, bags, suitcases, and parcels. The metal detector Checkpoint RS 600 is installed at the entrance and is designed to inspect people passing through the arch. Such devices are installed in shopping and entertainment centers, schools or preschools, train stations, ports and airports, stadiums and indoor areas, and checkpoints.
Characteristics
The device has an accessible control unit interface, so anyone can handle the settings, installation and connection. Most of the settings are automated. The new built-in processor has high power levels, which contributes to even faster analysis of scanned objects.
For the Checkpost RS 600 and arched metal detectors of the “Z” series, engineers have developed separate software that takes it to a new level of security.
The device can be connected in three ways, which significantly expands installation options. The arched metal detector Checkpoint RS 600 accurately detects metal objects and also automatically counts people passing through the arch.
Operating principle
The device uses radio waves to detect metal objects. Inside the two parallel beams of the arch there are antennas that send and receive radio signals. One wall sends a signal using antennas, and the second receives it and then returns it back. If a person carries metal objects, the signal does not pass through, since the metal blocks radio waves. A signal is triggered that tells the operator about the presence of metal objects in the belongings of a person passing through the metal detector.
Several devices can be installed in one room at once. Such a need may arise over a large area, as well as in places where there are several entrances. The devices are installed at a distance from each other. The distance depends on the sensitivity level and frequency compatibility. The most important thing is to prevent interference with radio waves. They can lead to false alarms of the equipment.
SPECIAL FEATURES
The “Blockpost RS-600” model is popular among the line of metal detectors. Excellent price-quality ratio and ease of operation make the Blokpost RS-600 model a leader in the metal detector market. The 2016 model is equipped with a remote control, which makes working with the detector much easier.
To simplify the work with the Checkpost RS-600 metal detector, we have developed a new design of the control unit and marking of parts, and also improved the fastening elements.
An accessible control unit interface, high safety, versatility of use, high sensitivity and noise immunity, a wide detection range, the ability to operate 24 hours a day in intelligent mode with simultaneous sound and light alarms, excellent technical characteristics make the model so popular.
Metal detectors "Blockpost" are safe for health. A low-intensity magnetic field is used for detection, which is safe for pregnant women and people with pacemakers or hearing aids.
INTEGRATION INTO THE ACCESS CONTROL SYSTEM
Having an output for controlling actuators (dry contacts), Blokpost RS-600 metal detectors can be integrated into an access control system. Metal detectors can be installed in conjunction with airlock cabins, airlocks, turnstiles, tripods, and automatic doors.
When a person passes through the metal detector with a prohibited item, a light and sound indication is triggered, the information is transmitted through a wired connection to the turnstile (gateway cabin, automatic door, etc.), which blocks further movement of the person. If there are no prohibited items, the turnstile will allow access.
PARALLEL OPERATION
The metal detector BLOKPOST RS-600, like its analogue BLOKPOST RS-800, has the ability to use up to 8 units during parallel operation at a distance of 50-70 cm from each other. The equipment has 8 operating frequencies, which reduces mutual interference between adjacent metal detectors, so the device can be used in parallel with other detectors. It is recommended to set different operating frequencies for
You can order Blokpost RS-600 metal detectors from SLS-GROUP LLC. We take care of issues related to delivery, so we organize delivery to any city by a transport company. You can receive a commercial offer by email. Leave a requestпabout the phone or on the website.
Performance characteristics (TTX):
| Number of independent detection zones | 6 |
| Number of sensitivity adjustment levels | 255 |
| Selectivity | Ferrous and non-ferrous metals |
| Degree of object localization | Accurate |
| Dust and waterproof coating | Yes |
| Number of passwords to change settings | 2 |
| Non-volatile memory for saving settings | Yes |
| Self-diagnosis test mode | Yes |
| Pass counter | Yes |
| Alarm counter | Yes |
| Alarm light notification | Yes |
| Alarm sound notification | Yes |
| Presence of LEDs in antenna panels | Yes |
| Remote control | Yes |
| Alarm volume range | 0…255 |
| Passage width | 700 mm |
| Independent sensitivity adjustment | Yes |
| Bandwidth | 60 people/min |
| Autonomous operation | Yes, option |
| Number of metal detectors when used in parallel (number of operating frequencies) | 8 |
| Increased noise immunity | The minimum distance between models is 45 cm |
| Operating temperature range | -20…+50°С |
| Power consumption | ≤ 20 W |
| Electrical voltage | 85-264V/47.5-60Hz |
| Passage dimensions | 1990 x 700 x 500 mm |
| External dimensions | 2230 x 835 x 580 mm |
| Net weight | 70 kg |
| Gross weight | 73 kg |
| Package Size - Antenna Panels | 2340 x 680 x 270 mm |
| Package Size - Control Unit | 820 x 490 x 310 mm |
| Average service life | 10 years |
| Guarantee | 1 year |
