X-ray television installation (introscope) “Di-Scan 100120”
X-ray television installation “Di-Scan 100120”one of the most popular installations of the “Di-Scan” series. The installation has proven itself to be the best at airport cargo terminals, temporary storage warehouses and customs offices. Wherever fast and high-quality control of medium and large-sized cargo is needed.
Performance characteristics (TTX): X-ray television installation “Di-Scan 100120”
| Tunnel size (WxH) | 1010 x 1205 mm |
| Overall dimensions of the installation (LxWxH) | 4150×2010×1900 mm |
| Conveyor height at floor level | 320 mm |
| Conveyor capacity | 200 kg |
| Operating temperature range | from 0 to +40 °C (in difficult climatic conditions it is possible to install additional cooling systems to avoid overheating) |
| Conveyor speed | 0.20 m/s |
| Installation weight | 1800 kg |
| Ready time | 20 sec |
| Work cycle | around the clock |
| Steel penetration | 34 mm |
| Resolution on copper wire | 0.1 mm |
| Radiation dose per inspection | Less than 1 mSv |
| Power supply | 220 V, 50 ± 1 Hz |
| Power consumption | 1.2 kW |
| Safety for films | ISO 1600 (33 DIN) |
| Functionality | — Coloring images according to organics
— Negative/positive — Stepped gamma correction — Scaling up to 32x — “Loop” mode — Reverse scanning function — Material recognition function by effective atomic number — Automatic diagnostics - Function to return previous images for more thorough analysis — Image archiving function (up to 50,000 images) — Automatic detection with an alarm signal of damaging metal elements weighing 1.5 kg and organic substances weighing 200 g with a probability of at least 95% — Determination of a group of substances by coloring them on the monitor screen in the following colors: a) yellow (orange) – light elements (0<Zeff.<10); b) green – medium-heavy elements (10<Zeff.<18); c) blue – heavy elements (18<Zeff.<40) while the color intensity conveys the thickness of the material — Possibility of recording received images onto a removable flash drive and transmitting them over a LAN (local area network) if the installation is connected to a consumer’s network — Ability to view the image library — Connection to a local network via TCP/IP protocol — Date/time display - USB 2.0, 3.0 |
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
