Document authentication device "Regula" 2003
Operational control of the authenticity of excise and special stamps; passports; identification cards and other documents proving identity and giving the right to cross the border; visa stamps and seal impressions, including for entry permits; driver's licenses, vehicle certificates, other documents related to vehicles, banknotes; securities and other documents with security measures against forgery.
Included in the State Register of Devices for monitoring the authenticity of securities and documents with a certain degree of security (including excise stamps), containing security elements that fluoresce in ultraviolet rays.
The device is made in the form of a small-sized block, which is permanently installed on the desktop. Plastic housing. Equipped with an ultraviolet light source. It has an enlarged working area above the object table. Power supply is from the network.
The design allows you to install a Regula 1001-1002 magnifying glass with 10x magnification (optional).
Functionality: control of basic means of printing protection, checking the presence/absence of absorption or fluorescent ultraviolet properties of materials.
Performance characteristics (TTX): Document authentication device "Regula" 2003
| ultraviolet light source, nm | 335 |
| overall dimensions (length×width×height), mm | 290×120×70 |
| weight, kg | 0.38 |
| supply voltage, V | 220–240 |
| nominal purity, Hz | 50 |
| rated current, A | 0.15 |
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
