X-ray television installation (introscope) ADANI BV6045DV (ADN 64D)
X-ray installation for inspection of luggage and goods “ADANI BV 6045DV”
The BV 6045DV installation is designed for visual inspection of various objects (parcels, luggage, cargo and other items) without opening them.
Dual-energy technology provides automatic color coding of materials with different atomic numbers and optical densities, which allows the operator to determine the presence of dangerous, undeclared or prohibited for import (export) objects.
Two projections allow you to obtain two images of an object from perpendicular angles in one scan, which gives the operator more accurate and complete information for detecting threats and does not require repeated scanning.
The BV 6045DV installation allows you to identify weapons, explosives, drugs, and other dangerous objects that pose a security threat.
Performance characteristics (TTX):ADANI BV6045DV
| Dimensions | |
| Dimensions of inspection tunnel - Width - Height |
610±3 mm 450±5 mm |
| Overall dimensions, no more - Width - Height - Length |
1200 mm 1350 mm 2350 mm |
| Weight, no more | 800 kg |
| Conveyor | |
| Maximum distributed load on conveyor |
200 kg |
| Cart height | 700 mm |
| Conveyor belt speed | 0.22±0.03 m/s |
| Sound level | < 60 dB(A) |
| X-ray source | |
| Number of sources | 2 |
| Anode voltage – Standard mode – High penetration mode |
140 kV 160 kV |
| Radiation direction | diagonally up |
| Cooling system | oil bath |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 65 536 |
| X-ray detector type | solid state photodiode with scintillation coating |
| Detective ability for copper wire |
0.08 mm (40 AWG) |
| Penetration ability on steel, standard mode | 30 mm guaranteed, 32 mm typical |
| Penetration ability on steel, mode increased penetrating ability |
36 mm guaranteed, 37 mm typical |
| Spatial resolution, line pairs per mm | 1.0 |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor and control | 2x LCD monitor 19.5” (1920x1080) with a specialized keyboard or 2x LCD monitor 21.5” (1920x1080) with a specialized keyboard or 2x LCD 21.5” multi-touch touch monitors with remote control |
| Image archive | 50,000 images |
| Power supply | |
| Voltage | 230 VAC ± 10% / 120 VAC ± 5% |
| Frequency | 50 / 60 Hz |
| Power consumption | no more than 1.2 kVA |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity (at + 20 °C) | up to 90%, no condensation |
| During transportation: | |
| – ambient temperature | -20° – +50 °С |
| During storage: | |
| – ambient temperature | -10° – +50 °С |
| – relative humidity (at + 35 °C) | up to 98%, no condensation |
