Two-projection X-ray television installation for inspection of luggage and goods SDT 7080 D
Modern, ergonomic, two-projection introscope. Provides the highest image detail, suitable for fast and efficient inspection of hand luggage, baggage, parcels, goods and bulky cargo.
Key Features:
▪ Possibility of choosing a 4 or 7 color palette.
▪ Accurate separation of substances by atomic mass:
only organic / mixed / only synthetic.
▪ Automatic detection of suspicious substances: hazardous liquids, explosives, drugs, weapons.
▪ Possibility of remote access via Ethernet network.
Main technical characteristics of the X-ray television installation SDT 7080 D
| Specifications | ||
| Installation size, mm (L x W x H) | 2992* x 1266 ±5 x 1576** | |
| Tunnel size, mm (W x H) | 690 x 795 ±10 | |
| Maximum power consumption, kW | no more than 1.2 | |
| System weight, kg | no more than 782 | |
| Penetration on steel, mm | 32-34 | |
| Number of projections | Two | |
| Conveyor belt speed, m/s | ≥0.2 | |
| Maximum distributed load on the conveyor, kg | 200 | |
| 3D function | No | |
| Maximum contrast on copper wire, mm | 0.1-0.13 | |
| Standard size | Average | |
| Conveyor height above floor level, mm | 301 | |
| Operating temperature | 0°С – +50°С | |
| Power supply | 220±10%V 55±5 Hz, with grounding | |
* – The length is indicated subject to the zero position of the conveyor belt tensioner. The tensioner stroke is no more than 30 mm.
** – The height is indicated from the transport wheels of the installation to the upper plane of the RTU. The travel of stationary legs is no more than 50 mm.
Equipment SDT 7080 D:
- X-ray television installation – 1 piece
- Automated operator workstation – 1 piece
- Operator control panel – 1 piece
- Cable set – 1 pc.
- Operational documentation, passport (form)
Additional options:
- Surveillance video surveillance kit (for recording luggage and its owner)
- Intelligent subsystem for automatic stop/start of the conveyor belt (extends the service life of the conveyor and saves energy consumption)
- Artificial intelligence-based subsystem for monitoring operator attention (vigilance / fatigue / operator absence from the workplace)
- Keyboard/mouse kit
- Voltage stabilizer
- Uninterruptible power supply RTU, automated workplace
- Specialized operator desk
- Additional monitor
- Roller conveyor
- Scat
