X-ray television installation (introscope) Rapiscan 620DV
X-ray television installation "Rapiscan620D.V.»
The “Rapiscan 620DV” X-ray television installation is an improved model with a 2-projection image construction and one of the most popular systems in the world for the inspection and control of hand luggage and baggage at airports, customs checkpoints, as well as at checkpoints of specially protected facilities. The system generates images after horizontal and vertical irradiation of the inspected object, which eliminates the need to re-scan the object. The ideal combination of basic tactical and technical characteristics makes this installation a leader in sales and operation in more than 50 countries around the world for inspection. The system's modular design and hinged, easily accessible panels provide excellent reliability and ease of maintenance. Exclusive developments in diode arrays and recognition and imaging algorithms are used, which provide maximum levels of detection of dangerous objects and separation of materials that are available to standard X-ray systems.
The system can also be equipped with the TARGET function, which allows you to automatically recognize potentially dangerous objects if their characteristics match those corresponding to explosives or drugs. The Rapiscan 620DV introscope is the new standard in security worldwide.
Performance characteristics (TTX): Rapiscan 620DV
| Tunnel size, mm | 640 x 430 |
| Overall dimensions of the installation | 2880 x 1418 x 1430 |
| Load capacity, kg | 165 |
| Operating temperature range, C | From 0 to +40 (in difficult climatic conditions it is possible to install additional cooling systems to avoid overheating) |
| Conveyor speed, m/s | 0.22 |
| Installation weight (NET), kg | 950 |
| Ready to work time, sec | 10 |
| Work cycle | around the clock |
| Penetration on steel, mm | 27 (guaranteed) / 30 (standard) |
| Resolution, mm | AWG 38 (standard) / 40 (guaranteed) |
| X-ray tube, voltage | 140kV (160kV option available with 35mm steel penetration) |
