X-ray television installation (introscope) Rapiscan 627DV
X-ray television installation "Rapiscan627D.V.»
The Rapiscan 627DV X-ray television installation is a popular system in the world for the inspection and control of large cargo at airports, customs checkpoints, and checkpoints of specially protected facilities. The Rapiscan 627DV introscope, thanks to a 1000 mm x 1000 mm tunnel and the use of 2 x-ray tubes, has the ability to construct a 2-angle image, which eliminates the need for additional scanning of a suspicious object in another plane.
The Rapiscan 627DV installation is indispensable when it is necessary to control large-sized cargo arriving at a facility that cannot be inspected using systems designed to control hand luggage and baggage. The Rapiscan 627DV RTU uses exclusive developments in diode lines and recognition and image formation algorithms, which provide maximum levels of detection of dangerous objects and separation of materials.
The system can also be equipped with the TARGET function, which allows you to automatically recognize potentially dangerous objects if their characteristics match those corresponding to explosives or drugs. Like all X-ray television units of the 600 series, Rapiscan 627DV is mounted on a standard platform, which simplifies maintenance and operation. The RTU has a dual-energy imaging function, the system has a streamlined ergonomic design and is equipped with multifunctional “Rapiscan OS600” software.
Performance and Technical Characteristics: Rapiscan 627DV
| Tunnel size, mm | 1000 x 1000 |
| Overall dimensions of the installation | 4559 x 2067 x 1968 |
| Load capacity, kg | 165 |
| Operating temperature range, C | From 0 to +40 (in difficult climatic conditions it is possible to install additional cooling systems to avoid overheating) |
| Conveyor speed, m/s | 0.22 |
| Installation weight, kg | 1653 |
| Ready to work time, sec | 10 |
| Work cycle | around the clock |
| Penetration on steel, mm | 35 (guaranteed) / 38 (standard) |
| Resolution, mm | 38 (standard) / 40 (guaranteed) |
| X-ray tube, voltage | 160kV (180kV option available with 42mm steel penetration) |
