X-ray television inspection installation “Berg 6040”
Introscope «Berg 6040"designed for contactless inspection and detection of hazardous substances in hand luggage and luggage of various objects. The device can detect prohibited items and substances inside luggage, which ensures security at a specific facility.
When setting up an X-ray television installation, it is necessary to take into account not only the throughput, but also the specifics of the specific facility where the device will be installed. The introscope is ready for use immediately after switching on, working smoothly. The operator receives high quality images in real time. It is transmitted to the computer or laptop monitor.
The device has a large set of useful options in the basic configuration; in addition, you can improve the installation by adding a number of additions, which makesintroscope Berg 6040universal device.
The scope of application is quite wide - the device is used at railway stations, border checkpoints and customs, at airports and post offices, commercial and public organizations.
Characteristics
Functionality in the basic configuration:
- identification of explosive substances and drugs;
- video recording of a person during the transfer of luggage to the device;
- the ability to transfer data to third-party media;
- built-in memory for up to 300 images;
- double-sided scanning.
The manufacturer offers to expand the device functionally by supplying additional systems for:
- alerts for people undergoing scans;
- operator training;
- measuring radiation levels at the operator’s workplace;
- luggage radioactivity checks;
- connecting a remote control, monitor or external media to the introscope.
The device meets standards and is certified in accordance with government regulations. You can order the Berg 6040 introscope from SLS-GROUP LLC. To receive a commercial offer, you must contact us by phone or send a request through the websitehttps://sls-security.ru/.
Tactical and Technical Characteristics (TTX): X-ray television inspection installation “Berg 6040”
| Name: | Meaning: |
| Tunnel size | 615x415 mm |
| Weight, net | 545 kg |
| Installation length | 2040 mm |
| Installation width | 827 mm |
| Installation height | 1285 mm |
| Maximum permissible load on the conveyor | 160 kg |
| Conveyor height | 682 mm |
| Conveyor speed | 0.2 m/s |
| Duty cycle | Around the clock |
| Steel penetration | 32 mm |
| Wire resolution | 0.0787 mm |
| Operating temperature | 0 ÷ +45 °C |
| Storage temperature | -40 ÷ +60 °C |
| Humidity | 20% – 95%, no condensation allowed |
| Display Mode | Black and white/color |
