X-ray television installation Berg 8065
The Berg 8065 X-ray television installation is designed for inspection of large bags, packages, medium and large boxes and other small and medium-sized luggage.
RTUS has a large number of options already in the basic configuration. And additional options make the Berg 8065 introscope a multifunctional X-ray television inspection system.
Areas of application for the Berg 8065 installation:
- Railway stations.
- Airports.
- Border checkpoints and customs.
- Judicial buildings.
- Government buildings.
- Post offices.
- Offices and shopping centers.
- Correctional facilities.
Basic equipmentRTU:
– B-Sight – detection of explosives and narcotic substances;
– B-Zoom – optimal scaling of the shadow image;
– B-TIP – operator vigilance training;
– B-Density– identification of areas with high density of material (to identify bladed weapons and firearms);
– B-View – video recording of a person when feeding luggage into the introscope for the purpose of automatically identifying the owner of the luggage;
– B-Export – transfer of shadow images to a USB drive in image format – JPG;
-B-Store – storage of shadow images in a maximum quantity of 200,000 pieces.
Additional installation options:
- Information system for persons undergoing inspection - “Assistant”;
- Operator training system;
- Radiation monitoring of the operator’s workplace;
- Radiation control of luggage;
- Remote console for connecting a remote control, monitor and USB storage devices;
- Possibility of integrating equipment into a single inspection complex;
- Scanning in two directions (reverse).
Tactical and technical characteristics (TTX) of the Berg 8065 introscope:
| Name: | Meaning: |
| Tunnel size | 810x650 mm |
| Weight, net | 800 kg |
| Installation length | 2885 mm |
| Installation width | 1108 mm |
| Installation height | 1673 mm |
| Maximum permissible load on the conveyor | 200 kg |
| Conveyor height | 285 mm |
| Conveyor speed | 0.2 m/s |
| Duty cycle | Around the clock |
| Steel penetration | 40 mm |
| Wire resolution | 0.127 mm |
| Operating temperature | 0 ÷ +45 °C |
| Storage temperature | -40 ÷ +60 °C |
| Humidity | 20% – 95%, no condensation allowed |
| Display Mode | Black and white/color |
