Single-projection X-ray television installation for inspection of luggage and goods SDT 8065
Modern and ergonomic single-project introscope with a protractor mounted at the bottom. Guarantees high image clarity and is designed for fast and efficient inspection of hand luggage, luggage and other bulky items.
Key Features:
▪ Possibility of choosing a 4 or 7 color palette.
▪ Accurate separation of substances by atomic mass:
only organic / mixed / only synthetic.
▪ Automatic detection of suspicious substances: hazardous liquids, explosives, drugs, weapons.
▪ Possibility of remote access via Ethernet network.
Main technical characteristics of the X-ray television installation SDT 8065
| Specifications | ||
| Installation size, mm (L x W x H) | 2747* x 1220 ±5 x 1465** | |
| Tunnel size, mm (W x H) | 810 x 652 ±10 | |
| Maximum power consumption, kW | no more than 1 | |
| System weight, kg | no more than 737 | |
| Penetration on steel, mm | 32-34 | |
| Number of projections | One | |
| Conveyor belt speed, m/s | ≥0.2 | |
| Maximum distributed load on the conveyor, kg | no more than 200 | |
| 3D function | No | |
| Maximum contrast on copper wire, mm | 0.1-0.13 | |
| Standard size | Average | |
| Conveyor height above floor level, mm | 301 | |
| Operating temperature | 0°С – +50°С | |
| Power supply | 220V±10% 55±5 Hz, with grounding | |
* – The length is indicated subject to the zero position of the conveyor belt tensioner. The tensioner stroke is no more than 30 mm.
** – The height is indicated from the transport wheels of the installation to the upper plane of the RTU. The travel of stationary legs is no more than 50 mm.
SDT 8065 equipment:
- X-ray television installation – 1 piece
- LCD monitor 24” – 1 pc.
- Operator control panel – 1 piece
- Operational documentation, passport (form)
Additional options:
- Input/output roller table 0.5 m
- Input/output roller table 1 m
- Exit ramp
- Built-in surveillance video cameras for recording luggage, objects and their owners
- Intelligent subsystem for automatic stop/start of the conveyor belt (extends the service life of the conveyor and saves energy consumption)
- Artificial intelligence-based subsystem for monitoring operator attention (vigilance / fatigue / operator absence from the workplace)
- Monitor with touch control
- Keyboard/mouse kit
- Voltage stabilizer
- Uninterruptible power supply
- Operator's desktop
