X-ray television installation for inspection of luggage and goods SDT 4030
Modern, ultra-compact, single-projection X-ray television installation with a lower conveyor location. provides the highest image detail, suitable for fast and efficient checking of correspondence, small parcels and hand luggage.
Features of SDT 4030
- Ultra-compact dimensions and low weight. Ideal for outdoor events, as well as for checking correspondence and small parcels
- User-friendly software interface and ergonomic operator control panel
- Innovative scanning technology with a palette of 7 colors
- More than 30 image processing functions
- Accurate separation of materials into organic, mixed, inorganic
- Built-in function for identifying suspicious objects based on artificial intelligence
- Windows-based software ensures high performance and stable operation
Function for highlighting suspicious objects
An assistant that allows the release of dangerous, flammable substances, explosives or drugs
Ability to select images in a 4-color or 7-color palette
Main technical characteristics of the X-ray television installation SDT 4030
| Specifications | ||
| Installation size, mm (L x W x H) | 1357* x 781 ±5 x 989** | |
| Tunnel size, mm (W x H) | 436 x 336 ±10 | |
| X-ray direction | Bottom-up | |
| Penetration on steel, mm | 16-18 | |
| Conveyor belt speed, m/s | ≥0.2 | |
| Maximum distributed load on the conveyor, kg | no more than 150 | |
| Color palette | Choice of: 4 or 7 colors | |
| Separation of objects by atomic mass | Availability | |
| Maximum power consumption, kW | no more than 0.7 | |
| System weight, kg | no more than 345 | |
| Number of projections | One | |
| 3D function | No | |
| Maximum contrast on copper wire, mm | 0.1-0.13 | |
| Conveyor height above floor level, mm | 299 | |
| Power supply | 220V±10% 55±5 Hz, with grounding | |
| Operating temperature | 0°С – +50°С | |
* – The length is indicated subject to the zero position of the conveyor belt tensioner. The tensioner stroke is no more than 30mm.
** – The height is indicated from the transport wheels of the installation to the upper plane of the RTU. The travel of stationary legs is no more than 50mm.
SDT 4030 equipment:
- X-ray television installation – 1 pc.
- Touch LCD monitor 21.5” – 1 pc.
- Operational documentation, passport (form)
Additional options available to order:
- Input/output roller table 0.5 m
- Intelligent subsystem for automatic stop/start of the conveyor belt (extends the service life of the installation and saves energy)
- Operator control panel
- Voltage stabilizer
- UPS
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
