Stationary arched metal detector RADARPLUS Model X
Stationary arched metal detector RADARPLUSRussian-made, designed for organizing inspections at sites with high traffic. Provides reliable detection of metal objects, is resistant to interference and is designed for intensive use in 24/7 operating conditions.
Model X Benefits
- 12 detection zonesby body height - precise localization of the object;
- High precision:probability of detection - no less98%;
- Individual sensitivity setting:from100 to 999 levelsfor each zone;
- Passage width from 700 to 1000 mm- at the customer's choice;
- Easy installation and setupwithout special training;
- Compatibility with ACS system,connection to a PC, possibility of remote control;
- Dust and moisture protection:IP20 (indoor use).
Details
RADARPLUS Model Xdesigned for screening personnel and visitors in buildings with increased security requirements: shopping centers, production facilities, institutions.
How to use
- Install a metal detector at the entry/exit point
- Connect power or activate the UPS
- Set sensitivity settings via the control panel
- Use Ethernet or Wi-Fi interface for setup and remote control
- When a threat is detected, a visual and audible alarm will sound
- Integrate the device with an access control system if necessary
Why do you need this
RADARPLUS Model X- an ideal solution for enterprises, institutions and public facilities where accurate, reliable and adaptable access control is required. It effectively prevents the introduction of prohibited items, minimizes false alarms and does not require complex maintenance.
- Improves the overall level of security;
- Reduces the burden on security personnel;
- Allows flexible adjustment of zones and sensitivity;
- Works stably in any conditions.
| Specifications | ||
| Passage width | from 700 to 1000 mm (customer’s choice) | |
| Detection zones | 12 | |
| Temperature | -20 to +55°C | |
| Dust and moisture protection | IP20 | |
| Installation location | room | |
| Housing material | impact-resistant plastic and metal | |
| Color | standard - gray (painting available on request) | |
| Indication | light and sound when a threat is detected | |
| Type of metals | magnetic and non-magnetic | |
| Sensitivity threshold | adjustable from 100 to 999 for each zone | |
Equipment:
- RADARPLUS Model X metal detector arch
- Control panel (standard or touch)
- Fastening kit
- Operating instructions
On request:
- Touch screen control
- Remote control with forced alarm function
- Temperature sensor
- Reversing counter input/output
- PC connection interface (Ethernet / Wi-Fi)
- RADARPLUS software (Russian language)
- Dry contacts (for integration with turnstiles, access control systems)
- Uninterruptible power supply up to 6 hours
Documentation:
Model X Declaration.Download
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
