Stationary arched metal detector RADARPLUS Model YZ
Price on request:
Request a price
Stationary arched metal detector RADARPLUSRussian-made, providing high-precision detection of metal objects and stable operation at sites with increased safety requirements.
Advantages of Model YZ
- 45 detection zones— ultra-precise localization of objects;
- Dust and moisture protection:IP20 (indoor use);
- Touch screen control— modern interface in Russian;
- Bandwidth:up to 80 people per minute;
- High detection accuracy— no less than 98%;
- Individual sensitivity adjustmentfor each zone;
- Selectivity class G- does not react to harmless personal items;
- Production: RADARPLUS (Russia)— complies with GOST and the requirements of government agencies.
How to use
- Install the device in the inspection area
- Connect power and, if necessary, backup source (UPS)
- Customize sensitivity levels and detection zones via touch interface
- Connect to access control systems or PC (when using additional modules)
- Carry out an inspection - when a metal object is detected, the area is highlighted and a signal is emitted
Why do you need this
- RADARPLUS Model YZ— a reliable solution for facilities with high security requirements:
- Ideal for street security checkpoints, train stations, stadiums, schools, concerts
- Allowsdetermine as accurately as possible the location of an object on the body
- Eliminates false alarms from harmless metal objects
- Easy to configure and integrate into existing security infrastructure
| Specifications | ||
| Passage width | from 700 to 1000 mm (customer’s choice) | |
| Detection zones | 45 | |
| Temperature | -20 to +55°C | |
| Dust and moisture protection | IP20 | |
| Installation location | room | |
| Housing material | anti-vandal metal housing | |
| Sensitivity threshold | adjustable from 100 to 999 for each zone | |
| Indication | light + sound when triggered | |
Equipment:
- Arch metal detector RADARPLUS Model YZ
- Touch screen control
- User instructions
- Mounting kit
- power unit
On request - extended kit with options:
- Remote control
- Temperature measurement function
- Reversible pass counter
- PC connection via Ethernet/Wi-Fi
- RADARPLUS software (in Russian)
- Dry contacts for integration with access control system
- UPS for autonomous operation up to 6 hours
Documentation:
Model YZ Declaration.Download
Model YZ Certificate.Download
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
