Stationary arched metal detector RADARPLUS Model Y
Stationary arched metal detector RADARPLUSRussian-made, designed for enhanced security checks in high-traffic areas. Suitable for government facilities, stadiums, schools and public events.
Model Y benefits
- 18 detection zones— high accuracy and minimal delays;
- Dust and moisture protection:IP20 (indoor use);
- Touch screen control— convenient data visualization and configuration;
- Bandwidth— up to 80 people per minute;
- Adjustable sensitivity— from 100 to 999 levels for each zone;
- High detection accuracy— no less than 98%;
- Low false positive rate— no more than 2%;
- Selectivity class G- does not react to glasses, watches, belts, jewelry;
- Made in Russia.
Functionality
- Touch screen: display of alarms, passages, trigger zones, interference scale
- Ability to save up to 5 user profiles
- Support for working with RADARPLUS software (Russian version)
How to use
- Install the metal detector in the desired area (indoors or under a canopy)
- Connect power and, if necessary, a backup source (UPS)
- Set up sensitivity zones and custom modes via touch interface
- Connect to ACS or Wi-Fi if necessary
- Carry out an inspection - when triggered, a light and sound indication is activated
Why do you need this
RADARPLUS Model Yis a universal solution for organizing an inspection system with high accuracy. It is necessary if:
- Operational security control at the entrance is required;
- We need precise localization of dangerous objects by zone;
- Fast passage is necessary - without delays and false alarms;
- It is necessary to integrate the inspection area into the existing security system.
| Specifications | ||
| Passage width | from 700 to 1000 mm (customer’s choice) | |
| Detection zones | 18 | |
| Temperature | -20 to +55°C | |
| Dust and moisture protection | IP20 | |
| Installation location | room | |
| Housing material | anti-vandal metal | |
| Color | gray (branding possible) | |
Equipment:
- Arch metal detector RADARPLUS Model Y
- Touch control controller
- power unit
- Mounting kit
- Operating instructions
When ordering options:
- Remote control
- Infrared temperature sensor
- Reversible pass counter (entrance/exit)
- PC connection interface (Ethernet/Wi-Fi)
- RADARPLUS software (Russian version)
- Dry contacts for integration into access control systems
- UPS for autonomous operation up to 6 hours
Documentation:
Model Y declaration.Download
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
